• Description
     04495-0D020
     HRK2386
     Brake Shoe Set
     SET

    Rear Axle
    Diameter : 200 mm
    Width : 32 mm

Brake Shoe Set:04495-0D020
Model Engine Chassis Type CYL year
BYD F0 Hatchback  9/08 - /
CITROEN C1 (PM_, PN_)  06/05 - /
JAC YUE YUE  8/12 - 2/15
OPEL AGILA (B) (H08)  4/08 - /
PEUGEOT 107  06/05 - /
SUZUKI SPLASH (EX)  1/08 - /
SUZUKI SWIFT III (SG)  8/05 - /
TOYOTA AYGO   07/05 - /
TOYOTA COROLLA Verso (ZER_, ZZE12_, R1_)  4/04 - 3/09
TOYOTA YARIS (_CP10)  0/01 - 9/05
TOYOTA YARIS VERSO (_P2_)  8/99 - 0/02


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
