• Description
     04465-30480
     HR1681
     Brake Pad Set
     PCS

    Front Axle
    Width : 117.6 mm
    Height : 58.7 mm
    Thickness : 17.3 mm

Brake Pad Set:04465-30480
Model Engine Chassis Type CYL year
LEXUS IS III (_E3_)  4/13 - /
TOYOTA (FAW) CROWN ROYAL (S180)  2/05 - 2/10
TOYOTA (FAW) CROWN ROYAL (S200)  2/09 - 2/15
TOYOTA (FAW) REIZ  0/05 - 9/10
TOYOTA CROWN Saloon (CRS_, JZS_, GRS18_, UZS_)  9/04 - 2/08
TOYOTA MARK X I (GRX12_)  5/04 - 9/09

Application

LEXUS IS250 AWD 2014


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
